The UXCAD Dynamic Curb subassembly creates a configurable curb section with control over flange, flowline, top front, and top back geometry. It is designed to let the user build curb conditions using either fixed dimensions, grades, or target-driven control points. This subassembly is useful for curb and gutter conditions where the curb shape needs to remain flexible while still maintaining consistent Civil 3D point, link, and shape coding.

Preview

UXCAD Dynamic Curb subassembly preview

Primary Use Cases

  • Standard curb and gutter sections
  • Flange-to-flowline controlled curb layouts
  • Flowline-to-top-front curb face control
  • Top-front-to-top-back curb cap control
  • Target-driven curb geometry
  • Code-controlled corridor surfaces and quantities

Attachment

The attachment point is located at the Flange, FlowLine and Top Back Curb of the curb section.

Input Parameters


Target Parameters


Enumerations

The UXCAD Dynamic Curb subassembly uses enumerations to simplify user control and reduce unnecessary parameter exposure. These dropdown-driven controls determine how geometry is calculated throughout the curb section.
Controls where the subassembly attaches to the corridor assembly.
Controls how the flange-to-flowline relationship is calculated.
Controls how the flowline-to-top-front curb face is calculated.
Controls how the top-front-to-top-back curb section is calculated.


Code List by Insertion Point

Flange

Flow Line

Top Back

Behavior

The curb is built from the flange point and continues outward through the flowline, top front, and top back geometry. Each major curb segment can be controlled by a fixed height, fixed grade, or target parameter depending on the selected control method.

Notes

Use this subassembly when the curb section needs to remain flexible across different design conditions without creating multiple separate curb subassemblies. Save your screenshots or Affinity graphics here:


Code List by Insertion Point

Flange

Flow Line

Top Back
